E10BK
Bracket made of pressed steel,zinc plated blue passivated finished.
Double ballraces swivel head strongly riveted together as one piece.
GN Elastic Grey Rubber Wheel
High quality elastic rubber 65° Shore A,vulcanized and chemically bonded to nylon wheel centre.
High load capacity,low rolling resistance,high wear resistance,quiet & comfort operation.
PAHs Free and REACH conform.
Temperature range - 20°C to + 80°C.
mm
|
mm
|
mm
|
|
mm
|
mm
|
mm
|
mm
|
mm
|
kg
|
|
|
|
| 80 | 35 | 12 |  |
105x85 | 82x62/78X58 | 9 | 105 | 34 | 150 | E10GN080PF | 011GN080PF | E10GN080PF-Q |
| 80 | 35 | 12 |  |
105x85 | 82x62/78X58 | 9 | 105 | 34 | 150 | E10GN080RF | 011GN080RF | E10GN080RF-Q |
| 80 | 35 | 8 |  |
105x85 | 82x62/78X58 | 9 | 105 | 34 | 150 | E10GN080BD | 011GN080BD | E10GN080BD-Q |
| 100 | 36 | 12 |  |
105x85 | 82x62/78X58 | 9 | 128 | 34 | 200 | E10GN100PF | 011GN100PF | E10GN100PF-Q |
| 100 | 36 | 12 |  |
105x85 | 82x62/78X58 | 9 | 128 | 34 | 200 | E10GN100RF | 011GN100RF | E10GN100RF-Q |
| 100 | 36 | 8 |  |
105x85 | 82x62/78X58 | 9 | 128 | 34 | 200 | E10GN100BD | 011GN100BD | E10GN100BD-Q |
| 125 | 36 | 15 |  |
105x85 | 82x62/78X58 | 9 | 156 | 32 | 200 | E10GN125PG | 011GN125PG | E10GN125PG-Q |
| 125 | 36 | 15 |  |
105x85 | 82x62/78X58 | 9 | 156 | 32 | 200 | E10GN125RG | 011GN125RG | E10GN125RG-Q |
| 125 | 36 | 10 |  |
105x85 | 82x62/78X58 | 9 | 156 | 32 | 200 | E10GN125BE | 011GN125BE | E10GN125BE-Q |
| 160 | 40 | 20 |  |
135x110 | 110x85/100x75 | 11 | 195 | 53 | 350 | E10GN161RH | 011GN161RH | E10GN161RH-Q |
| 160 | 40 | 15 |  |
135x110 | 110x85/100x75 | 11 | 195 | 53 | 350 | E10GN161DG | 011GN161DG | E10GN161DG-Q |
| 160 | 50 | 20 |  |
135x110 | 110x85/100x75 | 11 | 195 | 53 | 400 | E10GN160RH | 011GN160RH | E10GN160RH-Q |
| 160 | 50 | 20 |  |
135x110 | 110x85/100x75 | 11 | 195 | 53 | 400 | E10GN160DH | 011GN160DH | E10GN160DH-Q |
| 200 | 40 | 20 |  |
135x110 | 110x85/100x75 | 11 | 235 | 53 | 400 | E10GN201RH | 011GN201RH | E10GN201RH-Q |
| 200 | 40 | 15 |  |
135x110 | 110x85/100x75 | 11 | 235 | 53 | 400 | E10GN201DG | 011GN201DG | E10GN201DG-Q |
| 200 | 50 | 20 |  |
135x110 | 110x85/100x75 | 11 | 235 | 53 | 400 | E10GN200RH | 011GN200RH | E10GN200RH-Q |
| 200 | 50 | 20 |  |
135x110 | 110x85/100x75 | 11 | 235 | 53 | 400 | E10GN200DH | 011GN200DH | E10LN200DH-Q |
