210BK
Bracket made of heavy gauge pressed steel,zinc plated blue passivated finished.
Double ballraces swivel head protected by hardened steel with strong kingpin.
BS Elastic Black Rubber WheelHigh quality elastic rubber 65° Shore A.
Pressed thick steel centre welded to tubular steel hub.
High load capacity,shock and impact resistant,resistant to dirt,low rolling resistance.
PAHs Free and REACH conform.
Temperature range -20°C to + 80°C.
mm
|
mm
|
mm
|
|
mm
|
mm
|
mm
|
mm
|
mm
|
kg
|
|
|
|
| 160 | 50 | 20 |  |
135x110 | 105x80/75 | 11 | 205 | 65 | 450 | 210BS160DH | 211BS160DH | 210BS160DH-AQ |
| 200 | 50 | 20 | |
135x110 | 105x80/75 | 11 | 245 | 65 | 600 | 210BS200DH | 211BS200DH | 210BS200DH-AQ |
| 250 | 50 | 20 | |
135x110 | 105x80/75 | 11 | 295 | 65 | 700 | 210BS250DH | 211BS250DH | 210BS250DH-I |
